| Battery | |
|---|---|
| Battery A/H | 15 |
| Battery Description | Lithium Battery |
| Battery Voltage (V) | 48 |
| Battery W/H | 720 |
| Charging Time (Hour) | 7.5 |
| Max Range (KM) | 90 |
| Average Range (KM) | 50 |
| Battery Weight (KG) | 3 |
| Charger Model | DPower 54.6V DC2.1 Charger |
| Removable Battery | Yes |
| Throttle Range (KM) | 25 |
| General Specifications | |
| Colour | Matte Black or Matte White |
| Road Legal | Yes (250W) | No (750W) |
| Road Legality Note | 250W is road legal given the throttle is not unlocked and the max speed hasn't increased from the default 25km/h. 750W is for on off-road or on private property use only |
| Waterproof Rating | IP54 |
| Ergonomics | |
| Sitting Position | Upright |
| Grips Model | Velo High Performance Grips |
| Handlebars Type | Flat |
| Saddle Model | Justrek Gel Saddle |
| Accessories | |
| Front Basket | Optional |
| Bell | Yes |
| Bottle Holder | No |
| Front Carrier | Optional |
| Front Light | Yes (Integrated) |
| Mudguards | Yes |
| Rear Basket | Optional |
| Rear Light | Yes (Integrated) |
| Rear Rack | Yes |
| USB Charger | Yes |
| Wheel Lock | Optional |
| Brakes | |
| Brake Cut off Sensor | Yes |
| Brake Model | Tektro HD-E352 |
| Brake Pads Model/Material | E10.11/Organic Compound Pad |
| Brake Type | Hydraulic Disk Brakes |
| Rotor Size (MM) | 180 |
| Drivetrain | |
| Gear Set | Shimano Altus 7-Speed |
| Cassette Tooth | 11-34T |
| Chain Model | TEC C70 |
| Chainring Model | Prowheel Double-Wall Chainring |
| Chainring Tooth Count | 42 |
| Derailleur Model | Shimano Altus |
| Gear Shifter | Shimano Altus |
| Number of gears | 7 |
| Suspension | |
| Suspension Type | Front |
| Suspension Compression Adjustment | Yes |
| Suspension | Yes |
| Suspension Model | SR Suntour Performance Front Suspension Forks |
| Suspension Travel (CM) | 10 |
| Throttle | |
| Throttle | Yes |
| Throttle Type | Thumb |
| Default Throttle Max Speed (KM/H) | 6 |
| Throttle Max Unlocked Speed - For offroad Use (KM/H) | 40 |
| Tyre | |
| Tyre Size (Inch) | 29 |
| Tyre Brand / Model | Schwalbe Big Ben Plus Tyres |
| Tyre Width (Inch) | 2 |
| Puncture Resistant Tyres | Yes |
| Tyre Colour | Brown |
| Frame | |
| Frame Size (Inch) | 20 |
| Max Load (KG) | 120 |
| Frame Material | Aluminium |
| Frame | Step-Over |
| Rider Height Guide | |
| Rider Max Height (CM) | 195 (6′ 5″) |
| Rider Min Height (CM) | 176 (5' 9") |
| Motor | |
| Motor Power (W) | 250(500) Watt or 750 Watt |
| Motor Brand / Model | MXUS 250W Brushless Rear Hub Motor, MXUS 750W Brushless Rear Hub Motor |
| Default Maximum Speed (KM/H) | 25 |
| Motor Type | Brushless Geared Rear Hub Motor |
| Torque (NM) | 60 (250W) | 80 (750W) |
| Bike Geometry | |
| Axle to axle length (CM) | 115 |
| Handlebars Width (CM) | 69 |
| Total length (CM) | 189 |
| Bike Weight (KG) | 29 |
| Adjustable Handlebars Angle | No |
| Adjustable Seat Height | Yes |
| Box Gross Weight (KG) | 33 |
| Maximum Handlebars Height (CM) | 116 |
| Maximum Seat Height (CM) | 114 |
| Minimum Handlebars Height (CM) | 116 |
| Minimum Seat Height (CM) | 88 |
| Standover Height (CM) | 85 |
| Packaging Specifications | |
| Packaging Dimensions (CM) | L x W x D | 149 x 25 x 87 |
| Wheels | |
| Front Wheel Mount Type | Quick-Release Axle |
| Rear Wheel Mount Type | Nuts |
| Uncategorized | |
| Adjustable Handlebars Height | No |
- We offer FREE Shipping Australia-wide for orders over $100.
- Excludes WA, Regional Remote Areas And Islands.
- Note: Some Bulk Items may require an extra shipping charge.
- You will receive a Shipment Confirmation email once your order has shipped containing your tracking number(s).
- Our products are sent directly from our Redfern, Sydney Warehouse.
- All orders are processed within 2-4 business days.
- Shipping charges for your order will be calculated and displayed at checkout.
- In-store pickup is available for online orders.
- Choose the pickup option at checkout.
- For 24 hours hour click & collect, please give us a call to confirm your arrival time: 02 9171 7860
- PedL will allow a return for store credit, exchange product or refund provided the item in question is returned within 7 days.
- All our E-Bikes and E-Scooters come with 12 months warranty on all electronic and mechanical parts (including battery, motor, controller, display, suspension, wheels) and also 1-2 year warranty on the bike or scooter frame.
- If the product is damaged you can let us know at contact@pedl.com.au.
- Please ensure that you keep the box/packaging for your product in case the item needs to be returned.
- Full Shipping & Returns details: https://www.pedl.com.au/pages/shipping
- All products that are shipped are checked by the manufacturer and by Pedl mechanics however it is important that all bolts and screws on products are checked and tightened during assembly and before embarking on your first ride. This is the responsibility of the rider and Pedl will not be liable for any injury caused by improper assembly which includes misalignment and bolts not being checked for the correct tightness.
- It is the responsibility of the user to read and fully understand the literature provided by Pedl via email at sale for this product when purchased. This information includes, Battery care, Maintenance information and Warranty Information.
- Range and speed of this product will vary based on variables such as weight, terrain, degree of incline, wind, battery age, battery charge, speed reached and all other variables that would affect travel.
- Pedl advertises and sells its products for the purpose of recreational use. Each state and territory in Australia maintains a different set of rules and regulations for the usage of our products. It is the responsibility of users to ride with caution, wear a helmet and protective gear during use, and ensure compliance with local by-laws including requirements of use. Any information or representation provided by Pedl is of a general nature and may vary between users depending on individual circumstances.
- Please note that while we ensure all our bikes are carefully assembled and inspected before shipment, some minor adjustments may still be required. It is not uncommon for gears to be slightly misaligned, brake discs to rub, mudguards to be misaligned, or other adjustments to be needed after assembly. These issues are typically due to the natural settling of components during shipping and are considered a normal part of the assembly process. As such, these adjustments are not covered under Pedl’s warranty.
For best performance, we recommend that you have your bike assembled or inspected by a professional bike technician.
