SPECIFICATIONS
| 01. FRAME | Level 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 170mm travel, Forward Geometry, internal non-removable battery |
| 01A. FRAME | Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers |
| 02. FORK | Fox 38 29 Float FIT GRIP2 Factory Kashima, 180mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: high and low-speed compression, high and low-speed rebound, air preload |
| 03. REAR SHOCK | Fox DHX2 Performance Elite, 225x75mm. Settings: low-speed compression, low-speed rebound, spring preload. Trunnion top mount, 25x10mm bottom bushings |
| 04. SHOCK SETTINGS | Medium compression, medium rebound. Spring rate: S/M size 300 lbs, L size 350 lbs, XL size 400 lbs |
| 05. HEADSET | Onoff Saturn tapered for 1-1/8" to 1-1/2" head tube, ACB sealed bearings, top 41x30.2x7x45 degreex45 degree, bottom 51.9x40x8x45 degreex45 degree |
| 06. STEM | Onoff Sulfur FG 30mm 0 degree, 6061 forged alloy, 31.8mm barbore |
| 07. HANDLEBAR | Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 degree backsweep, 5 degree upsweep, 31.8mm barbore |
| 08. GRIPS | Onoff Desert, 1lock-on, 135mm |
| 09. SEATPOST | Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm |
| 10. SADDLE | FIZIK Terra Aidon X5 145mm |
| 11. FRONT BRAKE | Sram Code R, oversized 4-piston caliper, Centerline 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads |
| 12. REAR BRAKE | Sram Code R, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads |
| 13. BRAKE LEVER | Sram Code R, tool-free reach adjust |
| 14. FRONT HUB | e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts |
| 15. REAR HUB | e*thirteen Boost 12x148mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts |
| 16. FRONT TIRE | Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead |
| 17. REAR TIRE | Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead |
| 18. CRANKSET | Race Face Aeffect ebike, 165mm |
| 19. RINGS | Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD |
| 20. PEDALS | N/A |
| 21. CHAIN | Sram SX Eagle, 12s, Powerlock |
| 22. REAR DERAILLEUR | Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 |
| 23. CASSETTE | Sram PG-1210, 11-50T, 12s |
| 24. MOTOR | Bosch Performance Line CX Cruise (25Km/h) Smart System |
| 25. BATTERY | Bosch Powertube 750Wh |
| 26. DISPLAY | Bosch Kiox 300 / Bosch Mini Remote / Bosch System Controller |
| 27. DERAILLEUR HANGER | Mondraker M068 |
| 28. SIZES | S: 380mm / M: 420mm / L: 450mm / XL: 490mm |
