TOP SPEED
25KM/H
MOTOR POWER
250W
RANGE
50km-60km
BATTERY
417Wh 36V
CAPACITY
100kg
Ready to ride, the step through Coyote is perfect for mixed-terrain adventures and commuting. Featuring a 250w rear hub drive with 5 assist modes and a removable 417Wh battery, this bike ensures a comfortable and effortless ride. With a range of up to 60km, the Coyote 3 SO is perfect for long rides that cross between road, bike paths and some light dirt paths. Weighing approximately 29kg, this hardtail mountain bike is equipped with a HD rear rack, mudguards, and a kickstand. The 1x7 Shimano Tourney drivetrain means you will be able to tackle hills and also ride efficiently along flat paths and roads.
| Product Overview | |
|---|---|
| Product | Pedal Coyote 3 ST Electric Hardtail Mountain Bike |
| Colours | Sand / Slate Blue |
| Year Model | 2024 (Sand) / 2025 (Slate Blue) |
| Parent SKU | PedalCoyote3STSand / Pedal25Coyote3STTourGlossSlateGrey |
| Size SKUs |
SM: PDRDCOYTS7271 / PEEBPDEHR5245862 MD: PDRDCOYTM8056 / PEEBPDEHR5245879 LG: N/A / PEEBPDEHR5245886 |
| Barcodes |
SM: 9356844007271.00 / 9356844009862 MD: 9356844008056.00 / 9356844009879 LG: N/A / 9356844009886 |
| Product Features | |
| Frame Material | Alloy |
| Frame Style | Step-Through |
| Wheel Size | 27.5" (650b) |
| Brake Type | Hydraulic Disc Brake |
| Gears | 1 x 8 |
| Fork Material | N/A / Steel |
| Front Travel | 100mm |
| Charge Time | N/A / 5 Hours |
| Weight Limit | 100kg |
| Motor & Battery System | |
| Drive Type | Rear Wheel |
| Motor | CZJB 90T2 Rear Hub Geared Planetary Drive 250W 25KPH / CZJB 90T2 Planetary Drive |
| Torque | 40Nm |
| Climbing Ability | Flat to Modestly Steep Hills |
| Battery Size | 417Wh |
| Battery | Removable Downtube style UART w/Internal BMS / Removable 36V Eel Mini |
| Max Range | 60km / 50km |
| Display | KD58C / KD-58C |
| Build | |
| Frame | Step Through Alloy 6061 Removable Battery |
| Fork | Suntour XCM30 Coil QR / Coil Cast Alloy XCM30 w/Lockout |
| Handlebars | W:680mm R:28mm Backsweep:30° Barbore:31.8mm / Ergo Sweep Bar Style W:680mm R:28mm Backsweep:30° Barbore:31.8mm |
| Headset | A HEAD 28.6mm 44*56*30mm H/20mm Resin Black Cone / A HEAD 28.6mm 44*44mm w/15mm Resin Black Cone |
| Grips | JT-G107 135mm Closed End / JT-G106 Textured Rubber 125mm Closed End |
| Stem | A HEAD EXT:70mm H:41mm Barbore:31.8mm ED Bolt |
| Bottom Bracket | Sealed BSA Cartridge / Integrated |
| Pedals | 9/16 Platform Resin / 9/16 Resin Platform |
| Saddle | SW-1023 Black Foam / MTB Style SW-6670 Black Cover ED Rail |
| Seat Post | 30.6*350mm w/Alloy Head / 30.9*350mm w/Alloy Head |
| Accessories | Kickstand, 42V 2A Charger (3 Pin for 36V Battery), HD 4 Bolt Pannier Rack |
| Wheels | |
| Rims | RD-H20 27.5"*36H*14G Double Wall P/V w/Eyelets / RD-H20 27.5"*36H*14G Double Wall A/V w/Eyelets |
| Hubs | F: SF-A262F 36H QR 6 Bolt LBB / R: Hub Motor Nutted / F: SF-A262F M9 36H*13G / R: Jaibo Hub Motor |
| Tyres | W3102 MTB Knobbly 27.5" x 2.25" |
| Spokes | N/A / 14G Steel |
| Groupset | |
| Crankset | 38T ED Steel w/Alloy BLK CG 170mm / 38T ED Steel w/Alloy BLK CG 170mm Alloy Arm |
| Chain | KMC 7 Speed / KMC 8 Speed |
| Brakes | Tektro HD-M275 |
| Front Rotor | 180mm 6 Bolt |
| Rear Rotor | 160mm 6 Bolt |
| Shifters | Ltwoo Trigger 8 Speed / 8 Speed Trigger |
| Rear Derailleur | Shimano Tourney 8 Speed / Shimano 8 Speed |
| Cassette | 8 Speed |
