Description
SPECIFICATION
|
01. FRAME |
Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery |
|
01A. FRAME |
Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive p |
|
02. FORK |
Fox 36 29 Float FIT GRIP EVOL Rhythm, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: sweep adjust compression, Low-speed rebound, air preload |
|
03. REAR SHOCK |
Fox Float DPS Performance, 205x65mm. Settings: Compression 3 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings |
|
04. SHOCK SETTINGS |
medium compression, medium rebound, air volume spacer 0.4 |
|
05. HEADSET |
Onoff Saturn tapered for 1-1/8" to 1-1/2" head tube, ACB sealed bearings, top 41x30.2x7x45 degreex45 degree, bottom 51.9x40x8x45 degreex45 degree |
|
06. STEM |
Onoff Sulfur FG 30mm 0 degree, 6061 forged alloy, 31.8mm barbore |
|
07. HANDLEBAR |
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 degree backsweep, 5 degree upsweep, 31.8mm barbore |
|
08. GRIPS |
Onoff Twin, 1lock-on, 135mm |
|
09. SEATPOST |
Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm |
|
10. SADDLE |
MDK ebike black |
|
11. FRONT BRAKE |
Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads |
|
12. REAR BRAKE |
Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads |
|
13. BRAKE LEVER |
Sram DB8, tool-free reach adjust |
|
14. FRONT HUB |
Mavic, Boost 15x110mm, IS 6 bolts |
|
15. REAR HUB |
Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts |
|
16. FRONT TIRE |
Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead |
|
17. REAR TIRE |
Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead |
|
18. CRANKSET |
Race Face Aeffect ebike, 165mm |
|
19. RINGS |
Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD |
|
20. PEDALS |
N/A |
|
21. CHAIN |
Sram SX Eagle, 12s, Powerlock |
|
22. REAR DERAILLEUR |
Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 |
|
23. CASSETTE |
Sram PG-1210, 11-50T, 12s |
|
24. MOTOR |
Bosch Performance Line CX Cruise (25Km/h) Smart System |
|
25. BATTERY |
Bosch Powertube 750Wh |
|
26. DISPLAY |
Bosch Intuvia 100 / Bosch Mini Remote / Bosch System Controller |
|
27. DERAILLEUR HANGER |
Mondraker M068 |
|
28. SIZES |
S: 380mm / M: 420mm / L: 450mm / XL: 490mm |
